IMTP tower packings

Metal Intalox Saddle (IMTP) XINGFENG MetalIntaloxSaddles are the equivalent to Intalox Metal Tower Packing. Geometric ParametersSize (mm)Thickness (mm)Bulk density (kg/m3)Number (per m3)Free volume (%)Surface Area (m2/m3)Packing Factor (m-1)150.2528034700096.5305167250.325513500096.8241135400.42315020097.116179500.41491500098.110459600.4142840098.28550700.5113460098.66239The above data is reference to material stainless steel (AISI304) in the material thickness shown. Other material available: carbon steel, stainless steel including 304, 304L, 410,316, 316L.. Advantage 1)A versatile packing used in distillation, absorption and other operations. 2) Used in both deep vacuum and high pressure towers. 3) XINGFENG metal saddle is high performance random packing successfully used in mass transfer towers both small and large diameter. It is frequently used in deep vacuum towers where low pressure drop is crucial and also high pressure towers where capacity significantly exceeds conventional trays.
